Insole Department

Showing all 8 results

•

  Conveyor

  12 Mtr Long Insole/Outsole Preparation Conveyor

  Read more

  12 Mtr Long Insole/Outsole Preparation Conveyor

  Descriptions :

  - Stainless Steel Net, with electric heating tube oven (2x2M). - 2 mtr electric heating tube oven: 1KW * 12 set electric heating tube. - Blower: 1/4 HP * 6 set. - Transmission Cable 12 Meter: 35 mm² x 5 core cable. - Power: 7 kW (without light, light holder,...

•

  Skiving Machine

  Auto Shankboard Skiving Machine

  Read more

  Auto Shankboard Skiving Machine

  Descriptions :

  - Double Head (2 channels) - Power: 4.2 KW - Voltage: 380V/50Hz - Cutter Rotation Speed: 5100 RPM - Capacity: 1900 pcs/hour - Dimension: 1530x1100x1080 mm - Net Weight: 340 KG

•

  Latex Gluing MachineUncategorized

  Hard Roller gluing Machine for Shank board Complete with table, stand and induction Motor

  Read more

  Hard Roller gluing Machine for Shank board Complete with table, stand and induction Motor

  Descriptions :

  Glue Automatic Cycle device and sealed plastic storage device. The quantity of glue can be adjust freely. The Operation is simple and reliable performance. Motor Power: 0.37 KW Dimension: 750x420x390mm Weight: 50 KG

•

  Insole DepartmentUncategorized

  Hydraulic Insole Molding Machine

  Read more

  Hydraulic Insole Molding Machine

  Descriptions :

  - 2 Stations including Molds - Power: 1.5 KW - Pressure: 60 Ton - Dimension: 1000x600x1700 mm - Weight: 480 KG

•

  Insole Department

  Insole Edge Binding with Strap

  Read more

  Insole Edge Binding with Strap

  Descriptions :

  - Power: 0.55 KW - Capacity: 2000 Pairs/8 Hours - Dimension: 1210x550x1160 mm - Weight: 135 KG

•

  Latex Gluing Machine

  Latex Gluing Machine

  Read more

  Latex Gluing Machine

  Descriptions :

  - Glueing Machine for Insole and Shank Board 530mm - Automatic cycle device and sealed plastic storage device. Quantity of glue adjustable. - Motor Power: 0.37 KW - Dimension: 750x420x390 mm - Weight: 50 KG

•

  Insole Department

  Shank Rivet Fastening Machine

  Read more

  Shank Rivet Fastening Machine

  Descriptions :

  Motor Power: 0.37 KW Nailing Speed: 195 time/min Dimension: 680x450x1400mm Weight: 110KG

•

  Insole Department

  Vertical Insole Trimming Machine

  Read more

  Vertical Insole Trimming Machine

  Descriptions :

  - Adapts to trimming the edge of insole heel to make the surface smooth. - Can change speed automatically when trimming straight and round edges. - Power: 380V 1.1KW - Package Size: 900x950x1100 mm - Gross Weight: 165 KG / Net Weight: 128 KG
